Steel Wire Cutting Into Fixed Length

Steel Wire Cutting Into Fixed Length / Fixed-length prestressed steel wire is a type of steel widely used in prestressed concrete structures. It refers to steel wire that is cut or produced according to specific lengths and sizes.

It has the characteristics of high strength, low relaxation, good toughness and fatigue resistance. It can effectively establish and maintain prestress in prestressed concrete structures, improve the crack resistance, rigidity and durability of the structure.

Inquire Now

ADVANTAGES

- Generally, high-quality carbon steel billets are first subjected to surface treatments such as pickling and phosphating, and then cold-drawn or cold-drawn to achieve the specified strength and diameter before being cut to length. In order to improve its performance, subsequent treatments such as tempering and galvanizing may also be performed.

- Cutting the steel wire according to a pre-set fixed length to obtain steel wire segments that meet specific length requirements is often used in industrial production, construction and other fields. For example, when manufacturing products such as wire mesh and wire rope, the steel wire needs to be cut to a fixed length.

USE

Mainly used in various prestressed concrete structures, such as bridges, floor slabs and roof slabs of high-rise buildings, hydraulic structures, rock and soil anchoring and other engineering fields.

SPECIFICATIONS

The specifications of fixed-length prestressed steel wire are mainly divided by diameter. The common ones are 4.0, 5.0, 7.0, and 9.0 mm:

- 4.0 mm: commonly used for some components with relatively low prestressing requirements and small structural dimensions, such as small prestressed concrete slabs.

- 5.0 mm: widely used and can be used for general prestressed concrete beams and slab structures, and can meet certain bearing capacity and crack resistance requirements.

- 7.0mm: Suitable for large structures with high prestress requirements, such as prestressed beams of large bridges, etc., which can provide a large amount of prestress.

- 9.0mm: Commonly used in large hydraulic structures, giant frames of high-rise buildings and other structures with extremely high prestress requirements. Because of its large diameter, it can withstand greater tension.

In addition, there are some other non-standard or special specifications of fixed-length prestressed steel wires to meet the special needs of specific projects.

PACKAGE

We support customized packaging.

TAGS: Steel Wire Cutting Into Fixed Length, Pc Wire Cutting Into Fixed Length, Cut-To-Length Wire, Cut-To-Length Steel Wire, Wire Factory Price, Fixed Length wire, Steel Wire Cut Into Fixed Length
