Reinforcing Thread Bar

Reinforcing Thread Bar are further rolled by a high-precision rolling mill on the basis of hot-rolled ribbed steel bars. They have fine-rolled threads on their surface and can be closely matched with anchors, connectors, etc. They are mainly used for prestressed construction of large concrete structures. Prestress is applied by tensioning, and the elastic retraction of the steel bars is used to generate pre-compressive stress on the concrete, thereby improving the crack resistance, durability and bearing capacity of the concrete structure.

Inquire Now

ADVANTAGES

Advantages of Reinforcing Thread Bar:

High strength: high yield strength and tensile strength, stable and reliable quality. Common strength grades include PSB785, PSB830, PSB930, PSB1080, etc., which can meet the needs of different large-scale projects.

High precision: high dimensional accuracy, uniform thread specifications, regular tooth shape, ensuring the reliability and construction accuracy of connection with anchors.

Good machinability: good cold bending and welding performance, convenient for cutting, bending and connection at the construction site. Save steel bars, reduce component area and weight.

Strong adaptability of connection method: simple connection and anchoring, strong adhesion, safe and reliable tension anchoring, and convenient construction.

High corrosion resistance: generally surface anti-corrosion treatment is carried out, such as galvanizing, plastic coating, etc., which can effectively resist external environmental erosion and extend service life.

USE

Reinforcing Thread Bar Use:

They are mainly used for prestressed construction of large concrete structures. Prestress is applied by tensioning, and the elastic retraction of the steel bars is used to generate pre-compressive stress on the concrete, thereby improving the crack resistance, durability and bearing capacity of the concrete structure.

SPECIFICATIONS

Reinforcing Thread Bar is divided into grades according to yield strength, and its code is "PSB" plus the specified minimum yield strength. P, S, and B are the first letters of Prestressing, Screw, and Bars, respectively. For example: PSB830 represents a steel bar with a minimum yield strength of 830 MPa.

PSB500, PSB785, PSB830, PSB930, PSB1200, PSB1080/15mm, 20mm, 25mm, 28mm, 32mm, 36mm, 40mm, 50mm, 75mm and other specifications of precision rolled threaded steel.

Mechanical Properties：

Mechanical Properties
Diameter / mm	Cross-sectional area / mm	Weight Kg/m	PSB830				PSB930				PSB1080
			Min Yield Stress/Load		Min Ultimate Stress/Load		Min Yield Stress/Load		Min Ultimate Stress/Load		Min Yield Stress/Load		Min Ultimate Stress/Load
			Mpa	KN	Mpa	KN	Mpa	KN	Mpa	KN	Mpa	KN	Mpa	KN
15	177	1.4	830	147	1030	182	930	165	1080	191	1080	191	1230	218
20	314	2.47	830	261	1030	323	930	292	1080	339	1080	339	1230	386
25	491	4.1	830	408	1030	506	930	457	1080	530	1080	530	1230	604
32	804	6.65	830	667	1030	828	930	748	1080	868	1080	868	1230	989
36	1018	8.41	830	845	1030	1049	930	947	1080	1099	1080	1099	1230	1252
40	1257	10.34	830	1043	1030	1295	930	1169	1080	1358	1080	1358	1230	1546
50	1963	16.28	830	1629	1030	2022	930	1826	1080	2120	1080	2120	1230	2414
Elongation at fracture A / %			≥7				≥7				≥6
Total Elongation at max force Agt / %			≥3.5
Relaxation at 1000h			≤4
Modulus of elasticity / Mpa			2 x 10⁵

PACKAGE

we support environmental-friendly packaging ways.
